Corrosion Resistant Ptfe Teflon Gasket Filled With Carbon Fiber
Elevate your sealing solutions with Kaxite Sealing's Corrosion Resistant PTFE Teflon Gasket Filled With Carbon Fiber. This advanced gasket offers exceptional durability and chemical resistance, ideal for demanding industrial applications. Its unique carbon fiber reinforcement ensures superior performance, providing reliable, leak-free sealing that saves time and reduces maintenance costs, making it a smart choice for professionals seeking long-lasting efficiency.
Enhanced
PTFE product have strong corrosion-resistance and
friction-resistance.By adding filler such as glass fiber,carbon
fiber,graphite,MOS2.Al203,Carbon fiber powder, compression strength and
abrasion-resistance of the product is improved.In addition, it will have
good heat conductivity and low heat expansion coefficient.High
frequency coaxial coupling,Connector and attenuator in electronics and
telecommunication,Also it is applicable to various sealing
gasket,sealing plug or sealing seat in valves,air
conditioner,refrigerator and automotive parts as well as other apparatus
with high precision requirement.
Specifications
| outside diameter/inside diameter × height(mm) | outside diameter/inside diameter × height(mm) | outside diameter/inside diameter × height(mm) | outside diameter/inside diameter × height(mm) |
| 12.5/8.5 × 2 | 28/24 × 2 | 43/27 × 2 | 71/59 × 2 |
| 20/14 × 2 | 34/28 × 1.5 | 52/41.5 × 2 | 90/80 × 2 |
| 26/605 × 3 | 42/34 × 2 | 70/60 × 2.5 | 150/140 × 2.5 |
| 155/135 × 2 | 164/137 × 5 | 219/191 × 3 | 250/220 × 2 |
Properties
1.Working temperature:-180~+260°C
2.Melting point:327°C
3.Yield strength: 23MPa
4.Density: 2.2-2.3g/m3
5.Coefficient of friction<0.10
6.Strong chemical-resistant
Filling Material
|
Glass Fiber: |
Increases compressive strength, rigidity and wear. |
|
Carbon: |
Increases compressive strength, hardness, wear, and load properties. |
|
Graphite: |
Reduces coefficient of friction |
|
Molybdenum Disulfide: |
Increases hardness, stiffness, and wear |
|
Bronze: |
Increases hardness and wear resistance |
Technical Indexes
|
Properties |
Unit |
Result |
|
Apparent density |
g/cm3 |
2.10-2.30 |
|
Tensile strength (min) |
MPa |
30 |
|
Ultimate elongation (min) |
% |
300 |
| Product No. | Filled compound and content by weight | Tension strength MPa min | Ultimate strength% min | Compresive strength MPa min |
| 1 | 20% glass fiber | 10 | 120 | 16 |
| 2 | 25% glass fiber | 10 | 100 | 16 |
| 3 | 20% glass fiber graphile | 10 | 120 | 16 |
| 4 | 60% bronze | 10 | 80 | 20 |
| 5 | 15% carbon fiber | 11 | 130 | 16 |
| 6 | 24% bronze 12%glass fiber 6% graphite | 9 | 100 | 16 |
| 7 | 15%glass fiber 105polyikmide 5% graphite | 10 | 120 | 16.7 |
